SKYRC 1/8 Buggy Setup Station

Thanks to this setup system set in elegant black, which was specially designed for 1/8 buggies, almost all important parameters can be optimized conveniently and easily. After all, the better a RC car is set up, the more fun it gets when racing on the next track.

Adjustable Parameters

• Camber (+/- 10°)
• Toe (+/- 40°)
• Caster (+/- 20°)
• Steering

Includes
4x Measurement gauges for each suspension
1x Toe gauge

The Cheetah 1/10th 60A Sensored Combo set is ready to run out of box, combining the Cheetah 60A Sensored ESC, Cheetah Sensored Motor and Program Card.

This combo is perfect for 1/10th scale cars and trucks. With the included program card, you can modify settings settings such as cut-off voltage, brake and punch strength, drag brake and other parameters that add up to an incredible RC driving experience. You simply won't find a better power package for a more attractive price!

Not recommended for 4WD vehicles, and 3S should only be run on lightweight vehicles with 2590KV (13.5T) and lower KV.

ESC Specifications:

• Model: CS60

• Constant/Burst Current: 60A/380A

• Recommended Car: 1/10 and 1/12 Buggy and Touring Car, 1/10 and 1/8 Crawler

• Motor Limits: 2S LiPo: ≥8.5T(1/10 Touring), ≥10.5T(1/10 Buggy);  3S LiPo ≥10.5T(1/10 Touring), ≥13.5T(1/10 Buggy)

• Resistance: 0.0007 ohm

• Cell Count: 2-3S LiPo or 4-9S NiMH

• BEC Output: 6V@3A

• Size: 39x38x20mm (LxWxH)

• Weight: 30g (without wires)

• Fan: Included/5V@0.2A, Max 12.6V

• Connectors: Motor leads have bullet connectors pre-soldered for plug-and-play connection to ESC (must solder battery connector of choice)

This is SKYRC CTG-015 Digital Camber Gauge For 1/10 RC Touring Car. With a nonstop passion for RC car racing, SkyRC upgraded its mechanical predecessor with Bluetooth. The must-have RC Gears app definitely brings smartness to this gauge. Now our racers can measure the RC car's camber and toe angle and read the data on the phone and on the fly! RC suspension tuning made easy and smarter!

When it comes to RC grade racing, so many adjustments can contribute to the handling and performance of the vehicle. Adjusting Camber and Toe are vital adjustments to affect how your touring car performs on the straights and the turns. Toe In/Toe Out can be adjusted to increase or decrease steering and steering response.

Camber is the relationship of the tire to the ground, such that a tire that is perpendicular to the racing surface has zero camber. If the top of the tire leans in toward the car, it has negative camber; likewise, a tire that leans outward at the top has positive camber. Most RC touring cars will benefit from a negative camber degree, resulting in a slightly wider width and more static tire grip on the track surface, benefiting the turns and reducing roll-overs.

On your setup wheels, in your race wheels, or next to your setup station, CTG-015 will give you incredibly accurate readings on the camber angle of your wheels. The toe-tuning and camber-adjusting allow you to achieve your perfect tire wear and traction point. This accurate gauge allows you to tweak your camber and camber gain settings, finding peace of mind that you are following a precise, replicable and trustworthy measurement tool. All data can be read and kept on the phone!

SkyRC CTG-015 Digital Camber Gauge is built with Bluetooth 5.0, which enables a faster and more stable connection. The app instantly displays real-time data once connected. SkyRC Camber & Toe Gauge is even smaller than half iPhone 13 in size, convenient to carry around. The charge port is USB Type-C which is accepted as the de facto connector today, so most mobile phone cables can easily handle the charging.

Features:

• For: 1/10 RC Touring Car
• Material: Metal
• Color: Black
• Empowered edge for RC Gurus
• Camber and Toe Gauge Gets Bluetooth
• App control Real-time Display Via Bluetooth
• High Accuracy
• Measure Camber & Toe
• Small & Portable

Specifications:

• Input Voltage: 5V
• Input Current: 200-300mA
• Interface: Type C
• Working Voltage: 3.4-4.2V
• Working Current: ＜10mA
• Low-voltage Protection: ＜3.4V (Flashes Red)
• Measuring Range: ±17.5°
• Measuring Accuracy: ±0.2°
• Working Temperature: 0℃-50℃
• Working Humidity: 5%-90% (None-condensation)
• Storage Temperature: -10℃-50℃
• Storage Humidity: 1%-75% (None-condensation)

Includes:

• SkyRC CTG-015 Digital Camber Gauge (1 pc)

Introducing the SKYRC D200 Neo and Neo+, a revolutionary dual-port smart LiPo charger, designed for the avid RC hobbyist. This 800W charger is a game-changer in the world of battery management, offering unparalleled efficiency and versatility.

Efficient Dual-Port Charging: The D200 Neo's dual ports operate independently, allowing for simultaneous charging of two batteries. This feature is particularly beneficial for RC enthusiasts who require quick turnaround times. The smart power distribution ensures that once a battery is fully charged, the remaining power is redirected to the other port, maximizing charging efficiency.

Advanced Balance Charging: Balance charging is crucial for maintaining battery health and longevity. The D200 Neo excels in this area with its 1.5A balance charge current, ensuring that each cell in your battery pack is evenly charged, leading to improved performance and extended battery life.

Versatile Discharging and Battery Analysis: Not just limited to charging, the D200 Neo also features internal and external discharge capabilities. Its unique battery analyzer tool records voltage and current data, providing invaluable insights into your battery's performance and health.

Additional Features: The charger's flexibility extends to its function as a DC power supply, with adjustable output from 5V to 20V. It's equipped with a range of safety features, including a safety timer and maximum capacity shut-off, to prevent overcharging. The user-friendly interface offers a battery meter for checking internal resistance, a key indicator of battery health.

Get repeatable, numeric readings of your gear differential’s hardness so you can build, log, and exactly replicate winning setups instead of trusting "feel". That means fewer guess-and-check rebuilds and more consistent left/right and front/rear balance - helping you match handling to track grip and conditions across race weekends.

Just plug in any 5 V Micro-USB source (power bank, charger, laptop), attach the diff with the included adapter, press the button, and in 3–5 seconds you have a hard number you can record and compare. For maximum consistency, test at the same temperature - silicone oil viscosity changes with heat, and serious racers know that matters.

Precision-machined from a single block of anodized aluminum, the Diff Analyzer is only 54×28×24.8mm and 59g - small enough to toss in any pit bag or a pocket, tough enough for daily track use. Out of the box it works with all 1/10-scale gear diffs via the included 7mm hex (wheel-nut) and dogbone/pin/outdrive adapters. Optional adapters add 1/8-scale buggies/truggies and Mini-Z support, letting you standardize readings across your entire fleet.

Key specs

• Model: SK-500026
• Power: 5 V Micro-USB (any power bank or USB port)
• Test Time: ~3–5 seconds per diff
• Display: Clear white LED numeric value
• Compatibility: All 1/10-scale gear diffs (adapters included); 1/8-scale & Mini-Z with optional adapters
• Dimensions / Weight: 54 × 28 × 24.8 mm / 59 g
• Construction: CNC-machined anodized aluminum
• Included: 7 mm hex adapter + dogbone/pin/outdrive adapter for 1/10-scale

Data-driven diff tuning. Replicate fast setups. Win more mains.

The SkyRC FuriaX Supa Combo pairs the FuriaX Supa 60A brushless ESC with the FuriaX Supa 3650 sensorless brushless motor to form a matched 1/10 scale brushless system. It is aimed at drivers upgrading from brushed systems or basic RTR electronics in buggies, touring cars, short course trucks and drift chassis who want a reliable brushless combo without a complicated setup.

With KV options from around 2300kV up to 5400kV (depending on version), you can choose the combo suitable for your needs - either more torque or more speed: lower KV for heavier 1/10 trucks and off-road rigs like an Arrma Granite, higher KV for on-road and club-race builds based on platforms such as a Traxxas Slash or Losi 22. The system runs on 2-3S LiPo or 6–9 cell NiMH packs, so it drops neatly into most 1/10 RC car and truck layouts.

FuriaX Supa 60A Brushless ESC

The FuriaX Supa 60A ESC is the control side of the combo. It is rated at 60A continuous and up to 360A burst, and supports both sensored and sensorless brushless motors, though the included motor is sensorless. It is intended for 1/10 touring cars, buggies and short course trucks on 2–3S LiPo or 6–9S NiMH packs, with a compact footprint (about 48×38×38.5mm including fan) and a weight of roughly 100g so it will not upset the handling of most chassis.

Programming is done through SKYRC's RC Gears app on your phone, so you do not need a separate program box. From there you can set running mode (forward/brake, forward/brake/reverse, forward/reverse), drag brake, punch, maximum forward and reverse power, throttle neutral range, LiPo cutoff voltage, BEC output (6.0V or 7.4V), thermal cutoff level and motor pole setting. Cooling is handled by the integrated heatsink and fan, with airflow being the main requirement during installation.

• Current rating: 60A continuous / 360A burst
• Battery support: 2–3S LiPo or 6–9 cell NiMH
• Motor support: sensored or sensorless brushless motors for 1/10 applications
• Built-in BEC: selectable 6.0V or 7.4V for receivers and servos
• Configurable running mode, punch, drag brake, brake strength and reverse strength
• Adjustable LiPo cutoff, thermal protection and motor pole count
• Protection functions for low voltage, overheating and motor lock/stall conditions
• Approx. size and weight: 48×38×38.5mm with fan, about 100g

FuriaX Supa 3650 Brushless Motor

The FuriaX Supa 3650 is a 36×50mm 4-pole, 12-slot sensorless brushless motor built for 1/10 scale vehicles. Compared to a typical 2-pole 540-size motor, the 4-pole design produces more torque and smoother power delivery, which helps with controlled launches, steadier climbs and better throttle resolution on both dirt and pavement. Depending on the KV version, it is suitable for mixed-use buggies and trucks on 2S, or for higher-speed on-road setups on 2–3S.

Internally, the motor uses 0.2mm stator laminations, a 6061-T6 aluminum can, high-purity copper windings rated for high temperatures and sintered neodymium magnets rated to around 200°C. Pre-soldered 4.0mm gold-plated bullet connectors and color-coded ABC phase wires simplify wiring. The rotor is removable, which makes cleaning, bearing checks and any performance tuning more straightforward. It is designed to cope with dust and splashes encountered in normal off-road and car-park running, rather than being a fragile race-only part.

• Size: approx. 36mm diameter × 50mm length (3650 format)
• Design: 4-pole, 12-slot brushless sensorless
• KV options: commonly 2300kV, 3100kV, 3600kV, 4000kV and 5400kV, depending on the specific combo
• Battery rating (motor): up to 1–3S LiPo; the combo as a whole is used on 2–3S LiPo as limited by the ESC
• Construction: 0.2mm stator laminations, 6061-T6 can, high-temp copper windings and neodymium magnets
• Connectors: factory-installed 4.0mm gold bullets with ABC phase wiring
• Maintenance: removable rotor for easier cleaning and service
• Approximate weight: around 150g depending on KV version

Typical applications and compatibility

This combo is aimed at 1/10 hobby-grade RC cars where a driver wants a sensible brushless upgrade or replacement system. Typical use includes 2WD and 4WD buggies, touring cars, drift builds and short course trucks. It is a good fit for brushless conversions or electronics upgrades in vehicles like:

• Traxxas Slash, Rustler, Bandit, Stampede and similar 1/10 platforms
• Arrma Granite and other 2–3S 1/10 trucks when set up with appropriate gearing
• Tamiya TT-02 and similar touring chassis as a brushless conversion from the stock 540 motor
• Losi and Team Associated 1/10 buggies or short course trucks used for club racing or track days

If you are searching for an affordable 1/10 brushless combo, a 60A ESC and 3650 motor system for a brushless conversion, or a straightforward ESC + motor upgrade for a Traxxas, Arrma, Tamiya or similar 1/10 RC car, the FuriaX Supa Combo offers a practical option. It combines app-configurable ESC settings, sensible protections and a modern 4-pole motor in a package that installs easily and delivers predictable power from the first run.

Enhance Your RC Driving Experience: The SKYRC GC301 is a gyroscopic stability control device designed to revolutionize the way you drive your RC cars. By automatically adjusting steering based on gyro data, it ensures your vehicle maintains its intended path, offering unparalleled stability and control.

Customizable Performance: With an adjustable gain setting, the GC301 allows you to tailor the level of stability control to match your driving style or the demands of different racing conditions. This flexibility ensures optimal performance, whether you're navigating tight corners or accelerating down straightaways.

Advanced Technology for Superior Handling: This gyro stabilizer employs cutting-edge technology to detect and counteract unwanted vehicle movements, improving grip and preventing spin-outs. Its precision engineering makes it a must-have for any serious RC enthusiast looking to elevate their driving skills.

Easy Integration and Compatibility: Designed for easy installation, the GC301 seamlessly integrates with your RC car's existing setup. Its compact size and compatibility with a wide range of vehicles make it a versatile addition to your racing arsenal.

Drive with Confidence: By ensuring your RC car stays on its intended course, the GC301 adds a level of predictability to your driving. This not only improves lap times but also enhances the overall enjoyment of the hobby. Experience the difference in stability and control with the SKYRC GC301.

Knowledge is power! By knowing the facts before and after modifications, your efforts will not be in vain. GNSS Performance Meter will help you make sense of the improvements and help you make educated decisions to make sure you’re not spinning your wheels. For everyone trying to gauge their performance, here's an affordable way to do just that. Just got some new mods installed? Get some real feedback, really quickly. This is a professional-grade instrument accessible to enthusiasts. It’s every modeler’s dream. Enjoy!

Improved accuracy by tracking two satellite constellations
The GNSS Performance Analyzer supports GNSS(Global Navigation Satellite System) with GPS and GLONASS system that means more satellites are orbiting the earth. The advantage of this many satellites will definitely improve positional accuracy by tracking two satellite constellations instead of just GPS.

Small but Versatile
GNSS Performance Analyzer（GSM020) allows you to measure and analyze many aspects of your RC car & airplane’s performance using the latest GNSS engine (GPS, GLONASS) which gives you Acceleration, G-force, Speed, Time, Distance, High and Vertical Velocity. With its compact dimension of 40mm x 40mm x 17mm and internal antenna, it is an ideal choice for mounting on RC vehicles & airplanes.

Case Size: 40 x 39 x 16mm Weight: 38g

Peace of mind with built-in liPo battery
The 5 hours' up-time on the built-in rechargeable LiPo battery can give enough racing time to RC drivers or pilots in the field! With the micro USB charging port, it is very convenient to connect it to a USB port or another compatible USB power source for charging.

The GNSS PA App software automatically charts slope on as time elapses. Saved runs can be read by the App, allowing analyzing of average speed, maximum speed, and acceleration within the given time and defined distance. You can also define your own performance windows for measuring braking time, acceleration (e.g., 0-30 km/h, 10-50 km/h, 10 meters or any custom setting), G-force measurement, Max Speed, Average Speed, Distance, High and Vertical Velocity.

The meter can also be used as a speedometer and provides accurate logging of speed data.

The meter measures average speed，maximum speed，time elapsed，distance and altitude.

Visual LED indicator
The GNSS Analyzer is equipped with 3 LED indicators, signaling different operating modes. Open GNSS PA on the smartphone, the analyzer’s Bluetooth icon will stay steady blue, reflecting the device is connected; the satellite icon will stay steady green after a while of successful GNSS signal acquisition.

Built-in 1M Memory
The built-in 1M memory can record up to 50 records. And all the data can be transferred to the smartphone for analyzing! When the Flash is full, the previous record will be replaced automatically. Now you don't have to think about clearing data all the time or worry about missing the critical tracking data when the memory is full.

SKYRC B6AC V2 is the upgraded version for well-known iMAX B6AC. Compared with iMAX B6AC, it is more accurate and stable and also has some new features and functions. Users could set the terminal voltage by themselves and connect it to PC for PC control and firmware upgrade. What's more, users could also use it as Lithium Battery Meter and Battery Internal Resistance Meter. There are Automatic Charging Current Limit, Capacity Limit, Temperature Threshold and Processing Time Limit which makes the charger safer than V1.

SKYRC B6AC V2 is a high-performance, micro processor control charge/discharge station with battery management suitable for use with all current battery types, with integral equalizer for six-cell Lithium- Polymer (LiPo), Lithium High Voltage,Lithium iron phosphate(LiFe) and Lithium-Ion (LiIon) batteries; maximum 6A charge current and maximum 50W charge power.

Features:

• Dual Power AC/DC Input
• Temperature Probe Socket. If the temperature limit is reached, the process will be terminated.
• 2-6S XH Plug-in Balance Sockets
• The additional LiHV mode is able to charge the new generation of LiPo batteries with an end of charge voltage of 4.35 V.
• Depending on different kinds of batteries, there are different charging modes to meet users' request.
• PC Control: The user can monitor pack voltage, cell voltage and other data during the charging, view charge data in realtime graphs, and can also control the charger from "ChargeMaster".
• Program Data Store / load
• Battery Resistance Meter
• Battery Voltage Meter
• Maximum Safety
• Terminal Voltage Control

What’s in the Box:

• iMAX B6AC V2
• AC Power Cord
• DC Cable with Alligator Clip Charging Connector
• T Plug with Banana connector Charging Cable
• T Plug with Alligator Clip Connector Charging Cable
• T Plug with XT60 connector Charging Cable
• T Plug with Futaba connector Charging Cable
• T Plug with JST connector Charging Cable
• Instruction Manual

A must-have for RC hobbyists to track the temperatures.

Now you can take temperature measurement at a safe distance with SkyRC ITP380. RC hobbyists will never get burned or air blowing in your face from the RC vehicles, engines, motors, chargers, etc., while taking measurements.

You can trust SkyRC ITP380 to get accurate temperature readings from a safe distance, wherever indoor or outdoor.

SkyRC has engineered the ITP380 temperature measuring with accuracy down to the 0.1 °F and the object temperatures ranging from -40°F (-40°C) to 716°F (380°C).

SKYRC part number SK-500037

A complete, powerful brushless combo for a wide variety of 1/10 applications.

Includes a Leopard 60A V2 brushless ESC, a Leopard brushless motor and program card for less than what the other guys charge for an ESC, you can't beat this deal!

Enhance Battery Charging Safety with SKYRC's Temperature Sensor: This vital accessory for LiPo battery chargers is designed to monitor temperatures between 0°C and 80°C. Its primary function is to prevent overheating during the charging process, ensuring the safety and longevity of your batteries.

Compatible with SKYRC Chargers: This sensor seamlessly integrates with any SKYRC charger equipped with temperature sensing capabilities. The 45cm long wire and 22cm Velcro strap provide flexibility for various battery setups.

Easy Installation and Usage: The sensor is user-friendly, allowing for quick setup and immediate use. It is a crucial tool for RC hobbyists who prioritize battery health and safety during charging sessions.

Reliable and Accurate Temperature Readings: With its precise temperature range monitoring, this sensor ensures that your batteries are charged under optimal conditions, preventing damage caused by excessive heat.

Enhanced Safety for Your RC Adventures: The SKYRC Temperature Sensor is not just a tool, but a safeguard, ensuring that your charging process is safe and your batteries are always in top condition for your next RC outing.

Tired of that sinking feeling when you can't find your keys, wallet, or even your furry friend? Meet the SkyRC LocusTag – a smart, no-fuss Bluetooth tracker that hooks right into Apple's Find My network. It's like having a personal guardian for your essentials, using the massive web of Apple devices out there to ping locations in real time, all without any pesky subscriptions. If you're hunting for a reliable AirTag alternative that's easy on the wallet and tough enough for real life, this is it. Compact, clever, and certified for seamless Apple integration, the LocusTag turns "lost" into "found" faster than you can say "where'd I put that?"

Why You'll Love the SkyRC LocusTag

• Effortless Apple Find My Sync: Just pair it with your iPhone, iPad, or Mac, and you're set. Get instant alerts, share locations with family, and track down items using the app you already know and love – no extra downloads or fees.
• Handy Buzzer to the Rescue: Misplaced something close by? Hit play on the sound, and it'll chirp loud enough to hear through couch cushions or a messy bag. No more flipping the house upside down.
• Battery That Goes the Distance: The included CR2032 lasts over a year, and swapping it out is a breeze. Forget about constant charging; this tracker's ready when you are.
• Built Tough for Daily Adventures: At just 10 grams, it's lightweight but rugged, handling temps from -20°C to 60°C. Clip it to your backpack, bike, or pet collar – it'll keep up with your busiest days.
• Smart Alerts Keep You One Step Ahead: The built-in accelerometer senses motion and sends notifications if you wander off without your stuff. It's like an extra set of eyes on your valuables.
• Apple-Approved Reliability: MFi certified means it plays perfectly with iOS, so you get smooth, dependable performance every time.

Set It Up in Seconds

Pop out the battery tab, fire up the Find My app, and connect – that's all it takes. If you need to reset or change the battery later, a quick button press does the trick. It's straightforward, even if tech isn't your thing.

Works With What You Have

Designed for Apple's world:

• iPhone or iPod touch on iOS 14.5 or newer
• iPad running iPadOS 14.5 or later
• Mac with macOS 11.1 or above

What's Inside the Box

• One SkyRC LocusTag tracker
• Pre-installed CR2032 battery
• A handy lanyard to attach it right away

Life's too short to waste on searching for lost items. The SkyRC LocusTag gives you back that time, with smart tracking that's affordable, durable, and dead simple to use. Grab yours now and step into a world where everything stays found – you won't regret it!

If you keep a mix of AA/AAA packs for remotes and lights, plus 18650/21700 cells for flashlights or tools, the MC5000 lets you manage all of them from one bench-friendly unit. Four fully independent slots handle over ten chemistries (Li-ion, Li-ion HV, LiFe, NiMH, NiCd, eneloop, NiZn, RAM, LTO, and even emerging Na-ion), with precise control over charge/discharge and full readouts for capacity and internal resistance.

Why choose it

• One charger for almost everything: Works with 44+ cylindrical sizes - from AAAA and AAA/AA up to 21700/32700; up to two D-cells at a time. Spring-loaded rails make swaps quick.
• Real analysis, not just “charging”: See live voltage/current curves, mAh put back, and internal resistance to judge cell health and match sets.
• Fast, controlled charging: Up to 5.00A per slot (80W total). Discharge up to 2.00A for testing, cycling, and storage prep.
• Six useful modes: Charge, Discharge, Storage, Cycle, Refresh, and Break-in - available per chemistry.
• App control & updates: Built-in Bluetooth works with SkyRC’s SkyCharger app for remote monitoring and firmware upgrades.
• Extra utility on the bench: USB-C PD 65W output to power a laptop, tablet, or test gear while you work. (PD output takes priority over charge power.)
• Clear, quick operation: 2.8" color display, scroll wheel + two buttons, status LEDs, and triple-fan cooling.

Common questions:

What can I charge?
Single cylindrical cells from AAAA/AAA/AA, Sub-C, C, and D (two at a time), plus lithium sizes like 18350/18500/18650/18700/20700/21700/26650/32650/32700 and many in between. Protected 21700 cells fit.

How fast is it, really?
Set 0.05-5.00A per slot, subject to the 80W total. That’s enough to quick-charge high-capacity Li-ion or run proper “break-in” on NiMH at gentle rates. Discharge is 0.05-2.00A per slot for capacity checks or storage conditioning.

Does it run on AC or USB-C?
It has a built-in 100-240V AC power supply. The USB-C port is output only (PD 3.0 up to 65W). If you power a device from PD, the MC5000 prioritizes that power before sharing the remainder to the charge slots.

Is there an app?
Yes - SkyCharger for iOS and Android. Connect via Bluetooth to watch curves, log data, and perform firmware updates.

Can it prepare cells for storage or revive older NiMH?
Yes. Storage, Refresh, Cycle, and Break-in modes are built in, with chemistry-appropriate termination methods for NiMH/NiCd.

What’s in the box

MC5000 charger, AC power cord, quick-start guide.

Notes & safe use

• Do not charge primary (non-rechargeable) cells such as alkaline, zinc-carbon, CR123A/CR2.
• Follow your battery maker’s recommended charge rates; the MC5000 lets you set conservative currents for longevity.

The SKYRC twin motor cooling fan with housing fits 1/5 scale motor with diameter of 55/56mm and power connector can plug directly into any open channel of the receiver or BEC, it can reduce the temperature of the motor quickly and get the motor as cool as possible. Pushing your 1/5 scale car to the limit! The SKYRC twin motor cooling fan with housing fits 1/5 scale motor with diameter of 55mm and power connector can plug directly into any open channel of the receiver or BEC, it can reduce the temperature of the motor quickly and get the motor as cool as possible. Pushing your 1/5 scale car to the limit!

Features:

• Fan housing made of heat-resisting material
• Twin super big cooling fans with high rotation speed and good airflow
• Reasonable design with most cooling efficiency
• Easy to install and remove
• Two zip ties for easy and firm fastening

1. Fasten the fan to the motor with two zip ties.
2. Connect the power connector of the fan to any open channel of the receiver or to BEC. (Note: There is positive and negative polarity of the connector and make sure to connect it correctly.)
3. Once the system is powered on, the fan is working.

Specifications:

• Weight : 65g
• Input Voltage : 5-7.4V
• Cooling Fan : Twin 40x40x10mm with 500mm Length Cable and JR Male Connector
• Zip Ties Length : 250mm
• Suitable Motor Size : 55/56mm diameter, 90mm and longer
